Massive Management Device

ECC PLC
ECC PLC

ECC PLC

Capture Conveying Solar PV Production | Energy Consumption Data

Monitor & Control


  • Real-time load control and PV production monitoring

  • Web-based monitoring and control


Communication & Maintenance


  • Bidirectional communication for remote upgrades

  • Built-in industrial-grade PLC module

  • Remote operation and maintenance






Why ECC PLC

The SolaX Gateway ECC-PLC is a cutting-edge solution for capturing and conveying solar PV production and energy consumption data via RS485 to the Energy Control Center (ECC). It supports bidirectional communication,  enabling seamless remote maintenance and system adjustments.

With optional integrated production metering and consumption monitoring features, the ECC-PLC stands as a pivotal platform for intelligent energy management, optimizing energy efficiency and operational excellence.


ecc
FieldValue
ModelECC-PLC
Communication to MicroinverterCommunication Signal: PLC
Maximum Communicating Inverters*40
Communication to ECCS485: COM x 1, 115200bps, Modbus-RTU
AC Power Supply100-240VAC, 50-60Hz Single Phase (Three Phase Optional)
ECC-PLC Breaker2-Pole And Maximum 20 A Overcurrent Protection Required
Power Consumption5W
Dimensions mm (W x H x D)218 x 122 x 50
Weight Kg0.5
Operating Ambient Temperature Range [°C / °F]-40 to +60 (-40 to 140)
Installation MethodWall mounting / Rail mounting
CoolingNatural Convection
Environmental RatingIndoor -IP20
LED IndicatorsLED Indicator × 1 – RUN
CT SensorProduction and consumption metering
Meter AccuracyIntegrated PV production metering (+/- 1.0% via CT) and consumption monitoring (+/- 1.0% via CT)
CompabilityMicroinverter: A1 Micro Series
ComplianceCSA C22.2 No. 61010-1-12, UL 61010-1, CSA-C22.2 No. 61010-2-030, UL 61010-2-030, FCC
